Dryer equipment model TECFM suitable for vegetables and fruits (excluded cereals)
Modular structure made completely in aluminium pre-painted in white colour RAL9010 ; panels in fibreglass with internal foamy of polyhuretan at high density
- Automatic valves mount on balance and flowing on spherical bearings
- Trolley slide in AISI 304 stainless steel
- Diaphragm with fan and motor couples
- Vertical doors with inspection glass
- Fins air inlet
- “Champignon” device for the placing of the valve
- Electrical board for the automatic control complete with all accessories , protection and programming including thermometer electronic at digital reading for the automatic control of the temperature
- AISI 304 stainless steel piping for the extraction of the wet air complete with motorized closing shutters
- Dimensions of the equipment : 4000x2200x3050 mm
- Complete with nr° 2 trolleys in aluminium anticorrodal equipped with wheels
- Nr° 120 trays with food polyethylene bottom
- Electrical heating battery with capacity of 24 Kw/h
- Installed electrical power for ventilator : 1,5 KW
B02.a.) Additional set of 120 trays and 2 trolleys
Installation and start up : with our technician for a total period of 4 days – included travel, board and lodging costs for our technician
Packaging and transport
CE Marking : The proposed plant/machines has been designed and will be realized in conformity with the CE machinery directive 89/392 and subsequent integrations. The plant/machines will be provided of CE marking and related CE declaration of conformity.
